S-TEX 실리카 패킹 / Silica Fibre Square Packing 1000°C


특징
- 연속사용온도 1000ºC
- 유리화 되지 않습니다.(Does not vitrify)
- 복원력이 우수하여(Spring-back) 파손에 대한 내성이 우수합니다.
- 내화학성이 우수하여 유기물, 뜨거운 산(불화수소산 제외) 공격으로부터
  화학적 안정성을 제공합니다.

응용분야
- 산업용 보일러, 용광로, 차폐문, 스토브 방화문의 패킹
- 도어씰, 가스켓, 기밀 차폐 용도

실리카 패킹
공급규격(가로   x 세로 x 길이)
4mm x 4mm x 200M / Roll
5mm x 5mm x 200M / Roll
6mm x 6mm x 200M / Roll
8mm x 8mm x 100M / Roll
10mm x 10mm x 80M   / Roll
12mm x 12mm x 50M / Roll
14mm x 14mm x 50M / Roll
15mm x 15mm x 50M / Roll
16mm x 16mm x 50M / Roll
18mm x 18mm x 50M / Roll
20mm x 20mm x 50M   / Roll
22mm x 22mm x 30M / Roll
25mm x 25mm x 30M / Roll
28mm x 28mm x 30M / Roll
30mm x 30mm x 30M   / Roll
35mm x 35mm x 20M / Roll
40mm x 40mm x 15M   / Roll
50mm x 50mm x 10M / Roll
60mm x 60mm x 10M / Roll
70mm x 70mm x 10M / Roll
75mm x 75mm x 10M / Roll
80mm x 80mm x 10M / Roll
90mm x 90mm x 10M / Roll
100mm x 100mm x 10M / Roll


Basic Compositions of Silex Silica Fibre
SiO² 94.5%
Al²O³ 4.5%
Na²O < 0.5%
Further Components < 0.5%
General Properties of Silex Silica Fibre
Colour White
Average Fibre Diameter 9 microns
Bulk Density (chopped fibres 6mm) 50 kg/m³
Melting Point 1550°C
Weight Loss (1000°C, 2h) <10%
Linear Shrinkage (1000°C, 2h) 6%
Heat Resistance 1000°C - long term
1100°C
General Properties of Silex Silica Fibre Textile Products
• High Temperature Stability • Low Thermal Conductivity
• Excellent Thermal Shock Resistance • Incombustible
• Good Dimensional Stability • Good Chemical Resistance
• Low Density • Good Flexibility
