- 6 or 9μ E glass yarns(Non elastic stretch)
- E Glass 코어 로프 중앙에 삽입
- 검정색 공급가능
- 오일, 솔벨트 및 대부분의 화학 물질에 내성
- 연속사용온도 550ºC

응용분야
- 인슐레이션 자켓의 Draw cords
- 목재 버너 / 스토브 도어 씰 가스켓

품번	외경	판매 단위	롤 단위
GKRNSHT/NT/03	3mm	Roll	100m
GKRNSHT/NT/04	4mm	Roll	100m
GKRNSHT/NT/05	5mm	Roll	100m
GKRNSHT/NT/06	6mm	Roll	100m
GKRNSHT/NT/07	7mm	Roll	100m
GKRNSHT/NT/08	8mm	Roll	100m
GKRNSHT/NT/09	9mm	Roll	100m
GKRNSHT/NT/10	10mm	Roll	50m
GKRNSHT/NT/12	12mm	Roll	50m
GKRNSHT/NT/13	13mm	Roll	50m
GKRNSHT/NT/15	15mm	Roll	50m
GKRNSHT/NT/16	16mm	Roll	50m
GKRNSHT/NT/20	20mm	Roll	25m
GKRNSHT/NT/25	25mm	Roll	25m
GKRNSHT/NT/30	30mm	Roll	25m
GKRNSHT/NT/35	35mm	Roll	25m
GKRNSHT/NT/45	45mm	Roll	25m

Basic Compositions of E Glass Fibre
SiO²	53-55%
Al²O³	14-15.5%
CaO -MgO	20-24%
B²O³	6.5-9%
Fe²O³ - TiO²	< 1%
Na²O-H²O	< 1%
General Properties of E Glass Fibre
Colour	White
Max Temperature	550°C
Melting Point	1200°C
Diameter Filaments	> 6-9 microns
Tensile Strength - Virgin Filament	3400 MPa
Young’s Modulus	7400 MPa
Thermal Conductivity	1.0 W/m °K
Fire Reaction	Incombustible
Loss on Ignition	< 1.5%
Dielectric Rigidity-glass in Bulk	60-100 KV/mm
Solvent Resistance	Good
Bases Resistance	Good
Acid Resistance	Good - except fluoridic acid.
General Properties of E Glass Fibre Textile Products
• High Mechanical Strength	• Good Electrical Properties
• Incombustible	• Good Dimensional Stability
• Low Thermal Conductivity	• Good Resistance to Chemicals Agents
• High Thermal Resistance	• Good Flexibility
